Taconic TLY-5 Double Sided High Frequency PCB
collection

Type:High Frequency Pcb

View quote information
share:

PRODUCT DESCRIPTION

Taconic TLY-5

 Base Material

 Taconic TLY-5

 Board Thickness

 1.52 mm

 Copper Thickness

 1OZ

 DK

 2.2

 DF

 0.0009

 Solder mask Color

 Green

 Silkscreen Color

 White

 Surface Finishing

 ENIG

 Min.Quantity of Order

 No MOQ

 Certificate

 UL, ISO 9001, ISO 14001

 Difficulty

 Special Material


TLY laminates are manufactured with very lightweight woven fiberglass and are more dimensionally stable than chopped fiber reinforced PTFE composites. The woven matrix yields a more mechanically stable laminate that is suitable for high volume manufacturing. The low dissipation factor enables successful deployment for automotive radar applications designed at 77 GHz as well as other antennas in millimeter wave frequencies.

 Benefits:

  • Dimensionally stable

  • Lowest DF

  • Low moisture absorption

  • High copper peel strength

  • Uniform & consistent DK

  • Laser ablatable

Applications:

  • Automotive radar

  • Satellite/cellular communications

  • Power amplifiers

  • LNBs, LNAs, LNCs

  • Aerospace

  • Ka, E and W band applications



KingCredie follow the international standard manufacturing

  • ● IPC-4101 Specification for base materials rigid / multi-layer

  • ● IPC-600G Acceptability of Printed Boards / Class 2

  • ● IPC-6011 Generic Performance Specification for Printed Wiring Boards

  • ● IPC-6012B -Qualification and Performance Specification for Rigid Boards/class 2

  • ● IPC6013A- Qualification and Performance Specification for Flexible Printed Boards/class 2

  • ● IPC6016- Qualification and Performance Specification for High Density Interconnect(HDI) Layers or Boards/ class 2

  • ● IPC-SM-840 Qualification and Performance of permanent polymer coatings

  • ● MIL-PFR-55110 Military Performance and Specifications-Tucson

  • ● IPC-6018 Microwave End Product Board Inspection and Test-Tucson

  • ● IPC-TM-650 Test methods manual.
